ANTHEM – PURE PERFORMANCE, PURE VALUE
Since the AVM 50 and Statement D2 A/V Processors, music lovers and home theater enthusiasts have coveted Anthem’s premium surround separates. Featuring industry-leading room correction, expert management of the latest audio formats and robust integration; Anthem is the ultimate nerve center of any premium home theater or media room.
With the latest version of ARC Genesis Room Correction, a redesigned and more accurate calibration microphone, Anthem Web User Interface, an all-new electronics platform and a new modernized design; the new AVM A/V Processors bring all of today’s technologies into a single component.
Object-oriented audio codecs have been updated with support for up to 15.2 channels; as well as built-in streaming support for Apple AirPlay2, Google Chromecast, Bluetooth, Spotify Connect and Roon (coming soon).
Video support includes 7 HDMI 2.0 inputs with 2 outputs, plus eARC for seamless integration with smart TVs. Perfect passthrough of Ultra HD signals at up to 18.2 Gbps with Dolby Vision, HDR or Hybrid Log Gamma ensures optimal presentation of your visual media.
AVM70 SPEC
| PREAMPLIFIER (MEASURED AT XLR OUTPUT) | ||
| Maximum Output (<0.1% THD) | 10.7 VRMS, Subwoofer 11 VRMS | |
| Frequency Response | 20 Hz — 35 kHz (+/-0.2dB) | |
| Frequency Response, Analog-Direct | 20 Hz — 80 kHz (+0, -2 dB) | |
| THD+N (4 Vrms output) | -100 dB | |
| S/N Ratio (4 Vrms output, IEC-A filter) | 110 dB | |
| XLR Configuration | Pin 1: Ground, Pin 2: Positive, Pin 3: Negative | |
| POWER CONSUMPTION | ||
| Typical Load | 60 W | |
| Standby | 0.3 W | |
| Standby IP Control Enabled | 1.8 W | |
| Standby HDMI Bypass Enabled | 4.9 W | |
| DIMENSIONS | ||
| Height (without feet) | 6″ (15.24 cm) | |
| Height with Rackmount Kit | 4U | |
| Width | 17″ (43.18 cm) | |
| Depth (including wifi ant not power cord) | 14-1/2″ (36.4 cm) | |
| Weight | 22.1 lbs, 10.1 Kg | |
| POWER REQUIREMENT | ||
| 120 V version: | In countries where the line voltage is 120 V, this product operates from a single phase AC power source that supplies between 108 V and 132 V at a frequency of 60 Hz. | |
| 220-240 V version: | In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz. | |
