DA08-DSP
The Procella DA08-DSP is the first amplifier which is Designed by Procella Audio (Manufactured in China). The DA08-DSP has massive output power and can drive every Procella loudspeaker and subwoofer.
Delivering a solid 800W per channel at 8 ohms and 45A current this new Class-D amplifier will ensure a wide dynamic range with low-frequency impact and a transparent and musical sound quality that will satisfy the most critical listener.
This four-channel amplifier has 15 presets for all Procella subwoofers and full range speakers, from the P610 Mk2 to the V21 subwoofer.
Specifications
| OUTPUT POWER @ 4Ω/8Ω | 4x 800W |
|---|---|
| MAX. OUTPUT CURRENT | 45A peak |
| SIGNAL TO NOISE-RATIO | >105 dB A-weighted, 20 Hz-20 kHz, 8 Ω |
| THD+N (TYPICAL) | <0.05% (20 Hz – 20 kHz, 8 Ω load 3 dB below rated power) |
| FREQUENCY RESPONSE | 20 Hz – 20 kHz (+0/-0.5 dB 8 Ω load, 3 dB below rated power) |
| PROTECTION CIRCUITS | Short circuit protection, DC protection, Limiter, under voltage protection, over temperature protection, overload protection |
| OPERATING VOLTAGE/FREQUENCY | Universal Mains, 90-260V, 50-60Hz |
| CARTON CONTENT | Mains power cable, Adhesive rubber feet 4x, User guide |
| DIMENSIONS WXDXH /NET WEIGHT | 483 x 45 x 370 mm (1U) / 19” x 1.7” x 14.6”, 9,0 Kg / 19,8 Lbs |
| SHIPPING CARTON WXHXD / SHIPPING WEIGHT | 570 x 135 x 515 mm / 22,44”x 5,31”x 20,28”, 10 Kg / 22.05 Lbs |
| ASSEMBLY | Designed by Procella Audio, Manufactured in China |
